C9335 brake drum (disc) lathe suitable for small car
Item No.: 207
Applicable for repairing small brake drum/disc.
Feeding can be either manual or auto.
Two faces of brake disc can be turned simultaneously.
Feeding can be either manual or auto.
Two faces of brake disc can be turned simultaneously.
Description
Applicable for repairing small brake drum/disc.
Feeding can be either manual or auto.
Two faces of brake disc can be turned simultaneously.
Feature
1. Quickly, accurately and efficiently to cutting rotor.
2. Fast and slow setting allow cutting rotor.
3. Quickly, accurately and efficiently to cutting drum.
4. Finitely adjustably setting allow cutting drum.
5. Three kinds of speed 70, 88, 118 rpm to choose for spindle speed.
6. A convenient design allows to quickly change from rotor to drum, with cross feed extension plate will be increase the maximum rotor diameter to 22'/588mm.
7. Position of stop make the lathe stop automatically after cutting.
8. Fully equipped with adapter package.
Specification
Range of Processing diameter (Brake Drum): 180-350mm
Range of Processing diameter (Brake Disc): 180-350mm
Rotating Speed of Workpiece: 75/130(r/min)
Max Travel of Tool: 100mm
Feeding capacity: 0.15mm/r
Motor Power: 1.1Kw
N.W/G.W: 200kg
Accessories
Package
Warranty: 12 months
Lead time: One week
